Blog about this project: https://www.emoe.xyz/diy_ccd_camera/ (Chinese)

or https://www.bilibili.com/read/cv41529294/ (Chinese)

1. FPGA Core board --- Open source ZYNQ7000 Board from oshwhub.com
2. CCD Base board --- "CCD_Sensor_ZYNQ_Based_Board" Folder (KiCAD >= 8)
3. Handle and Lens Mount --- "3d_model" Folder (FreeCAD >= 1.0)

1. "pixel_rearrange.py" for pixel re-arrangement

2. GIMP for gamma correction

3. Fitswork4 for debayer

4. Photoshop and the "CCD_CameraRAW_Preset" for color grading

5. Vivado 2018.3 and "CCD_Cam_Vivado_workspace.7z" for both PL and PS source code

   Note: Due to Github file size limitation and I dont want to upload the whole workspace folder (because that is a mess), So the workspace is split into two smaller compressed files.

Some sample photo
