FlowKit is a powerful distributed system that enables you to create AI pipelines using an intuitive graph-based interface. Design complex workflows visually, and let FlowKit handle distributed execution across worker nodes with automatic scaling and zero downtime.

• Graph-Based Pipeline Design - Build AI workflows visually with a drag-and-drop interface
• Distributed Execution - Automatically distribute workload across multiple worker nodes
• High Availability - Zero downtime with intelligent task scheduling and failover
• Auto-Scaling - Dynamically scale resources based on workload demands
• Secret Management - Secure storage and injection of API keys and sensitive data
• Real-Time Monitoring - Track execution paths, inputs, outputs, and system resources
• Isolated Execution - Run untrusted code safely in isolated VM environments

FlowKit consists of six core components working together to provide a robust distributed pipeline execution system:

The main worker node responsible for executing individual pipeline nodes. NPUs run in isolated VMs to safely execute remote code and process tasks. its have only connection to Node runner no connection to db or any internal system components

Acts as a bridge between NPUs and the FlowKit Control Unit. Responsibilities include:

• Task scheduling and distribution
• NPU management and monitoring
• Secret resolution from Secret Manager
• Health checks and failover handling

Secure storage for sensitive data such as API keys and credentials. Secrets can be referenced in node code using the syntax {{{secret::KEY_NAME}}}, which Node Runner resolves before execution.

Provides comprehensive observability by tracking:

• Node inputs and outputs
• Execution paths and timing
• Error logs and stack traces
• Performance metrics

The orchestration engine that executes pipelines. It maintains the Flow Control Block (FCB), which contains:

• Current execution state of all nodes
• Pipeline control flow logic
• Pause/resume/restart capabilities

A web-based interface connecting users to all FlowKit services:

• Visual graph editor for pipeline design
• Secret management interface
• Real-time execution monitoring
• Resource utilization dashboards

Nodes are the building blocks of FlowKit pipelines. Here's a simple example:

from flowkit.node import Node
from flowkit.log import Logger

node = Node()
logger = Logger(node)

# Reference secrets using the secret manager syntax
api_key = "{{{secret::OPENAI_KEY}}}"

async def main():
    # Get inputs from previous nodes
    inputs = node.get_inputs()

    # Process data
    result = inputs["a"] + inputs["b"]

    # Log execution progress
    for i in range(10):
        await logger.info(f"Processing step {i}")

    await logger.info(f"Using API key: {api_key}")

    # Return: error_outputs, success_outputs, status_message
    return [], {"out": result, "key": api_key}, "run successfully"

# Register and run the node
node.register_main(main)
node.run()

return nodes, success_outputs, status_message

• nodes: List of nodes which execute next
• success_outputs: Dictionary of outputs for successful execution paths
• status_message: Human-readable execution status

Design complex AI workflows with an intuitive drag-and-drop interface. Connect nodes, configure parameters, and visualize your entire pipeline.

Securely manage API keys, credentials, and sensitive configuration data. All secrets are encrypted at rest and resolved at runtime.

Monitor system health and resource utilization in real-time:

Under Load

Idle State

Track CPU, memory, and network usage across all NPUs and make informed scaling decisions.

• Isolated Execution - Each NPU runs in a separate VM for maximum security
• Encrypted Secrets - All sensitive data encrypted at rest and in transit
• Access Control - Role-based permissions for pipeline and secret management
• Audit Logging - Complete audit trail of all system operations

FlowKit provides comprehensive monitoring through the Flow Trace Monitor:

• Real-time execution tracking
• Input/output inspection at every node
• Performance metrics and bottleneck identification
• Error tracking with detailed stack traces
• Historical execution data and analytics
